2V800AH AGM Deep Cycle Battery
2V800Ah battery, agm deep cycle battery, rechargeable solar battery
Quick Details:
Model Number:2VHC800(2V800Ah)
Dimension: 410*176*330*365
Certification:CE,UL,ISO14001,ISO9001
Weight:49kg
OEM:Availble
Terminal:RT(M10)
Color:Black or grey
Capacity:800Ah
Sealed Type:Seald
Battery Type: Maintenance Free
Usage: Photovoltaic systems, Renewable Energy Systems, Outdoor control Equipments, Electric Utilities, Solar/Wind/Hybrid power systems, DC power supply, Security and fire alarm systems, Emergency lighting systems
Lead Time:
Quantity(Pieces) | 1 - 50000 | >50000 |
Est. Time(working days) | 25~35 | To be negotiated |
Features and Benefits:
2V800AH AGM Deep Cycle Battery
• Designed floating charging service life: 15 years (25ºC)
• Sealed and maintenance free operation
• Safety valve installation for explosion proof
• Low self-discharge characteristic
• Wide operating temperature range from 0ºC~40ºC
• Lead Aluminum calcium Tin alloy high energy, prevent corrosion
Specification:
NOMINAL VOLTAGE | : 2V |
NOMINAL CPACITY(10hr) | : 800Ah |
DIMENSIONS | |
TOTAL HEIGHT | :365mm ( 14.37 inches ) |
CONTAINER HEIGHT | :330mm ( 12.99 inches ) |
LENGTH | :410mm (16.14 inches) |
WIDTH | :176mm ( 6.93 inches) |
WEIGHT | : APPROX 49.0Kg ( 108.03 lbs) |
CONTAINER MATERIAL | : UL94HB ABS |
: UL94V-0 ABS | |
INTERNAL RESISTANCE ( 25°C,77°F) | : ~0.38mΩ |
DISCHARGE CAPACITY UNDER DIFFERENT TEMPERATURES | |
40°C | : ~103% |
25°C | : ~100% |
0°C | : ~86% |
“VHC” deep cycle series adopts advanced AGM valve regulated technology, for example: thick plate design, special grid alloy, special paste formula, high temperature curing technology...
The recovery performance from deep discharge is excellent. It is widely used for frequent deep cycle applications, especially for Solar, Wind and other renewable energy storage systems.
Applications:
• Uninterruptable Power Supply (UPS)
• Telecommunication
• Emergency lighting
• Fire alarm and security systems
• Medical appliance
• Solar applications
• Electronic test equipment
• Electronic measuring devices
• Geophysical devices
• Marine equipment
Our advantages:
1. Specialized in batteries field more than 20 years, has plenty experiences of manufacturing and exporting.
2. Good quality battery with reasonable price. Comprehensive product system to meet customers' needs.
3. Capable to custom make for our customers according to their requirements.
